| Green Mode |
| DoE Level VI, CoC Tier 2 |
| No Load Power Consumption Less Than 0.15W |
| Model | O/P Voltage (V) | O/P Current (A) |
| AC120V4.00-CS* | 12 | 4 |
| AC120V5.00-CS* | 12 | 5 |
| AC150V4.33-CS* | 15 | 4.33 |
| AC160V4.00-CS* | 16 | 4 |
| AC165V3.90-CS* | 16.5 | 3.9 |
| AC185V3.50-CS* | 18.5 | 3.5 |
| AC190V3.42-CS* | 19 | 3.42 |
| AC195V3.33-CS* | 19.5 | 3.33 |
| AC200V3.25-CS* | 20 | 3.25 |
| AC240V2.70-CS* | 24 | 2.7 |
| (*) are blank, or 3 or 4, means C8, C6, C14 Inlet |
| Input |
| Voltage | 100 - 240VAC |
| Line Frequency | 50-60Hz |
| Current | 1.3A Max. for 65W |
| Protection | Internal Primary Current Fuse |
| Configuration | IEC60320/ C6, C8, C14 |
| Output |
| Load Regulation | ± 5% (Typical) |
| Ripple | 2% Vp-p Max. for Output Voltage @ Full Load |
| Transient Response | 0.5mS for 50% Load Change Typical |
| Holdup Time | 10mS @ Full Load |
| Protection | Short Circuit Protection/ Over Voltage Protection/ Over Current |
| Protection |
| DC Cord | 20AWG / 18AWG |
| Ferrite Core | NO |
| Safety Approvals (EN / IEC / UL 62368) |
| CB / UL / cUL / FCC / GS / CE |
| Electrical |
| Topology | Switching Flyback |
| Dielectric Withstand | 3,000 VAC Primary – Secondary |
| Leakage Current | 0.25mA @ 2 Pin / 3.5mA @ 3 Pin |
| Efficiency | DoE Level VI, ErP Stage 2, CoC Tier 2 |
| EMI Conduction&Radiation | Compliance to EN55032：2015+A1:2020 |
| Harmonic Current | Compliance to EN61000-3-2：2019 |
| EMS Immunity | Compliance to EN55035:2017+A11:2020 |
| MTBF | 300,000 Calculated Hours at 25°C, by Telcordia SR-332 |
| Environmental |
| Operaturing Temperature | 0 to +40°C |
| Storage Temperature | -20 to +80°C |
| Relative Humidity | Operating: 20 to 80% RH |
| Storage: 10 to 90% RH |
| Cooling | Natural Convection Cooling |
| Mechanical |
| Case Dimension | L113 x W49 x H30 (mm) |
| Weight | 250g (Ref.) |
