| Features | |
| GaN technology is applied | |
| USB-C & USB-A port , with Power Delivery 3.0 | |
| Wall-Mount type | |
| Half the size and weight less than a normal design | |
| AC 100-240V Input worldwide, | |
| Energy-saving and latest-technology chipset and components applied | |
| High transformation efficiency, good insulating properties, thermal effects, long life | |
| Charge compatible device exceptionally quickly | |
| Universal, Compatible with Laptops with USB-C port DC-In, including MAC, Thinkpad, HP, LENOVO, ASUS, ACER, GOOGLE etc and USB-C enabled smartphones and tablets. | |
| Green Mode | |
| Meeting DoE Level VI, CoC Tier2 | |
| Average Efficiency > 90% | |
| Input | |
| Voltage | 100-240 VAC worldwide, |
| Line Frequency | 50-60Hz |
| Current | 1.0A Max. |
| Protection | Internal Primary Current Fuse |
| Configuration | fixed AC Plug (US/CN/UK/KCC/Brazil... ) |
| Output | |
| Power | PD 45Watts |
| Ratings | Single USB-C 5V3A、9V3A、12V3A、15V3A、20V2.25A. (45W Max) Single USB-A 5V2.4A (12W Max) USB-C+ USB-A 31W+12W (45W Max) |
| Load Regulation | ± 5%; |
| Protection | Short Circuit Protection/ Over Voltage Protection/ Over Current |
| Protection | |
| DC output | USB-C & USB-A port |
| Safety Approvals | |
| CE / CB / GS/ ETL / cETL / EN / EC / UL / 62368 | |
| Electrical | |
| Dielectric Withstand | 3,000 VAC Primary – Secondary |
| EMI Conduction & Radiation | Compliance to EN55032：2015+A1:2020 |
| Harmonic Current | Compliance to EN61000-3-2：2019 |
| EMS Immunity | Compliance to EN55035:2017+A11:2020 |
| MTBF | 300,000 Calculated Hours at 25°C, by Telcordia SR-332 |
| Environmental | |
| Operaturing Temperature | 0 to +40°C |
| Storage Temperature | -20 to +80°C |
| Relative Humidity | Operating: 20 to 80% RH |
| Storage: 10 to 90% RH | |
| Cooling | Natural Convection Cooling |
| Mechanical | |
| Case Dimension | 54 * 48 * 29mm |
| Weight | 100g (Ref.) |
