| Features |
| GaN technology is applied |
| Single USB Type-C port |
| Wall-Mount type |
| Half the size and weight less than a normal design |
| AC 100-240V Input worldwide, |
| Energy-saving and latest-technology chipset and components applied |
| High transformation efficiency, good insulating properties, thermal effects, long life |
| Charge compatible device exceptionally quickly |
| Universal, Compatible with Laptops with USB-C port DC-In, including MAC, Thinkpad, HP, LENOVO, ASUS, ACER, GOOGLE etc and USB-C enabled smartphones and tablets. |
| Green Mode |
| Meeting DoE Level VI, CoC Tier2 |
| No Load Power Consumption Less Than 0.1W |
| Average Efficiency > 89% |
| Input |
| Voltage | 100-240 VAC worldwide, |
| Line Frequency | 50-60Hz |
| Current | 1.1A Max. |
| Protection | Internal Primary Current Fuse |
| Inlet |
|
| Exchangeable EU/UK plug available |
| Output |
| Power | PD 65Watts |
| Ratings | 5V/9V/12V 3A, 15V 3A, 20V 2.25A |
| Load Regulation | ± 5%; |
| Protection | Short Circuit Protection/ Over Voltage Protection/ Over Current |
| Protection |
| DC output | 1 USB-C port |
| Safety Approvals |
| CE / CB / GS/ ETL / cETL / EN / EC / UL / 62368 |
| Electrical |
| Dielectric Withstand | 3,000 VAC Primary – Secondary |
| EMI Conduction & Radiation | Compliance to EN55032：2015+A1:2020 |
| Harmonic Current | Compliance to EN61000-3-2：2019 |
| EMS Immunity | Compliance to EN55035:2017+A11:2020 |
| MTBF | 300,000 Calculated Hours at 25°C, by Telcordia SR-332 |
| Environmental |
| Operaturing Temperature | 0 to +40°C |
| Storage Temperature | -20 to +80°C |
| Relative Humidity | Operating: 20 to 80% RH |
| Storage: 10 to 90% RH |
| Cooling | Natural Convection Cooling |
| Mechanical |
| Case Dimension | 60 * 57 * 28mm |
| Weight | 140g (Ref.) |
